MUM-14

Lightweight and Robust

The Multi-use MUM-14 Mini-Monocular is a high performance modular, hand-held passive night vision monocular device that utilizes a single intensifier tube to provide crisp, clear images under the darkest conditions.
Small and versatile, the MUM-14 Mini-Monocular gives you a high performance 2nd or 3rd generation system in the smallest, toughest package available. The MUM-14 has the ability to be weapon mounted, head/helmet mounted, hand-held, optionally attached to extender 3x/5x Afocal objective lenses.
Also available is the dual-system head/helmet mount that allows two Mini Monoculars to become one binocular system.

MUM-14

Multifunctional

Adopts to any Mission

The MUM (also known as the MiNi-14) Night Vision Multi-Purpose Monocular is also one of the lightest night vision monoculars on the market. Developed as an alternative to the US Military issue AN/PVS-14, these units offer extreme operational performance and are waterproof down to 20m.

Specification

Weight & Specs

Finish Matte Black, Corrosion Resistant
Fibre re-enforces polycarbonate body
Capability Built-in IR LED with “IR-on” indicator in FOV
Automatic high-light cutoff
Low battery indicator in FOV
Waterproof: 20m for two hours
Exceeding MilStd-810
Magnification: 1X
FOV: 40º
Objective Lens: Objective Lens: 27mm, F/1.2
Ocular Lens: EFL 26mm
Diopter: +4 to -6
Focus: 15cm to Infinity
Power: One (1) Lithium CR123 or one (1) Alkaline AA
Battery Life: Approx. 40 Hours (CR123A) or 20 Hours (AA)
Weight: 260g
